Ideal for wedding videographers, drone camera operators, and multimedia journalists who have professional photo still and cinema video production needs, the EOS R5 C Mirrorless Cinema Camera from Canon offers a new type of shooting experience. With a simple switch, the R5 C is a full featured still photo camera with all the settings of the R5 EOS mirrorless camera. When switched in the other direction, it becomes a full-frame 8K60 Cinema EOS camera that internally records 12-bit Cinema RAW Light footage. There's no need to carry a second camera to your production when stills and video are available within a single compact design.
The R5 C enhances a number of features in comparison to its siblings the R5 and C70, including 4K120 recording, HDMI RAW output, Canon Log 3 HLG/PQ support, unlimited recording time, a timecode port, Dual Pixel CMOS AF with eye detection, an active cooling system, a high-power LP-E6NH battery, 13 reassignable buttons, and a multifunction shoe for XLR adapters. The camera also retains the reliable features of those cameras including Wi-Fi/Bluetooth, footage compatibility with DaVinci Resolve and Canon apps, an electronic RF mount, CFexpress/SD card slots, a similar button layout, and more. The EOS R5 C is also dust and moisture resistant to the same level as its cinema cousin, the EOS C70. All this is packed into a tiny 1.7 lb body that is just asking to become your go-to drone camera.

Imaging
Lens Mount
Canon RF
Sensor Resolution
Actual: 47.1 Megapixel
Effective: 45 Megapixel (8192 x 5464)
Image Sensor
36 x 24 mm (Full-Frame) CMOS
Sensor Crop (35mm Equivalent)
Crop Factor: 1x
Additional Modes: 1.5x/1.6x/3x
*Additional Crop Occurs in Select Video Modes
Image Stabilization
Digital
Built-In ND Filter
No
Capture Type
Stills & Video
Exposure Control
Shutter Type
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
Shutter Speed
Electronic Shutter
1/8000 to 0.5 Seconds
Electronic Front Curtain Shutter
1/8000 to 30 Seconds
Mechanical Shutter
1/8000 to 30 Seconds
Bulb/Time Mode
Bulb Mode
ISO/Gain Sensitivity
Native in Manual Mode: 100 to 51,200 (50 to 102,400 Extended)
Native in Auto Mode: 100 to 12,800 (100 to 51,200 Extended)
Video
Native: 100 to 51,200 (50 to 102,400 Extended)
Metering Method
Center-Weighted Average, Evaluative, Partial, Spot
Exposure Modes
Aperture Priority, Auto, Manual, Program, Shutter Priority
Exposure Compensation
-3 to +3 EV (1/3, 1/2 EV Steps)
Metering Range
-3 to 20 EV
White Balance
2500 to 10,000K
Presets: ATW, AWB, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent, Shade, Tungsten
Continuous Shooting
Up to 20 fps at Maximum Resolution for up to 83 Frames (Raw) / 170 Frames (JPEG)
Interval Recording
Yes
Self-Timer
2/10-Second Delay
Still Image Capture
Aspect Ratio
1:1, 3:2, 4:3, 16:9
Image File Format
C-RAW, HEIF, JPEG, Raw
Bit Depth
14-Bit
Video Capture
Internal Recording
Cinema RAW Light/Raw 12-Bit
8192 x 4320 at 23.98/24.00/25/29.97/50/59.94 fps [1030 to 2570 Mb/s]
5952 x 3140 at 23.98/24.00/29.97/50/59.94 fps [544 to 1360 Mb/s]
2976 x 1570 at 23.98/24.00/25/29.97/50/59.94 fps [138 to 344 Mb/s]
AVC-Intra/AVC-LongG/XF-AVC 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/59.94/100/120 fps [160 to 810 Mb/s]
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100/120 fps [160 to 810 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s]
1280 x 720 at 50/59.94 fps [8 to 12 Mb/s]
AVC-LongG/MP4 4:2:2 10-Bit
DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps [400 to 540 Mb/s]
UHD 8K (7680 x 4320) at 23.98/25/29.97 fps [400 to 540 Mb/s]
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94/100/120 fps [100 to 225 Mb/s]
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/120 fps [100 to 225 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 to 50 Mb/s]
DCI 2K (2048 x 1080) at 23.98/24.00/25/29.97/50/59.94 fps [35 to 50 Mb/s]
1280 x 720 at 50/59.94 fps [8 to 12 Mb/s]
AVC-LongG/MP4 4:2:0 8-Bit
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94/120 fps [100 to 225 Mb/s]
UHD 4K (3840 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps [100 to 225 Mb/s]
1920 x 1080p at 23.98/24.00/29.97/50/59.94 fps [35 to 50 Mb/s]
DCI 2K (2048 x 1080) at 23.98/24.00/25/29.97/50/59.94 fps [35 to 50 Mb/s]
1280 x 720 at 50/59.94 fps [8 to 12 Mb/s]
Video Output
4:2:2 10-Bit via HDMI
DCI 4K (4096 x 2160) up to 59.94 fps
UHD 4K (3840 x 2160) up to 59.94 fps
Fast-/Slow-Motion Support
Yes
Gamma Curve
Canon Log 3, HDR-HLG, HDR-PQ, Rec709, Rec2020
Recording Limit
No
IP Streaming
No
Built-In Microphone
Mono
Audio Recording
Raw: 4-Channel
MP4: 4-Channel
Interface
Media/Memory Card Slot
Slot 1: CFexpress Type B
Slot 2: SD/SDHC/SDXC (UHS-II)
Video I/O
1x Micro-HDMI Output
1x USB-C Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O
1x USB-C Input
Other I/O
1x Canon N3 Remote Input
1x DIN 1.0/2.3 Time Code Input
1x USB-C (USB 3.2 / 3.1 Gen 2) Data Output (Shared with Power Input/Video Output)
Wireless
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 5.0 Control
Mobile App Compatible
Yes: Android & iOS
App Name: Canon Camera Connect
Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)
GPS
*Adapter Required or Via Connected Smartphone
Monitor
Display Size
3.2"
Resolution
2,100,000 Dot
Display Type
Free-Angle Tilting Touchscreen LCD
Viewfinder
Type
Electronic (OLED)
Size
0.5"
Resolution
5,790,000 Dot
Eye Point
23 mm
Coverage
100%
Magnification
Approx. 0.76x
Diopter Adjustment
-4 to +2
Focus
Focus Type
Auto and Manual Focus
Focus Mode
Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points
Phase Detection: 1053
Autofocus Sensitivity
-6 to +20 EV
Flash
Built-In Flash/Light
No
Maximum Sync Speed
1/250 Second
Flash Compensation
-3 to +3 EV (1/3, 1/2 EV Steps)
Dedicated Flash System
eTTL
External Flash Connection
Shoe Mount
General
Battery
1x LP-E6NH Rechargeable Lithium-Ion, 7.2 VDC, 2130 mAh (Included)
 • Approx. 220 Shots
or
1x LP-E6N Rechargeable Lithium-Ion (Not Included)
or
1x LP-E6 Rechargeable Lithium-Ion (Not Included)
Shoe Mount
1x Hot Shoe
Tripod Mounting Thread
1x 1/4"-20 Female (Bottom)
Operating Conditions
32 to 104°F / 0 to 40°C up to 85% Humidity
Dimensions (W x H x D)
5.6 x 4 x 4.4" / 142.2 x 101.6 x 111.8 mm
Weight
1.5 lb / 680 g (Body Only)
1.7 lb / 770 g (With Battery, Recording Media)
Packaging Info
Package Weight
3.205 lb
Box Dimensions (LxWxH)
9.5 x 7.9 x 7.9"
